Three privacy layers, each usable on its own:

• Shielded amount (default) — every CETCH, T_MINT, CXFER, T_AXFER and burn-change output is a 33-byte Pedersen commitment plus an 8-byte encrypted amount. Pool notes use the same commitment.
• Shielded address (opt-in) — the sender pays to commit = recipient_pubkey + b·G, with b derived from ECDH between sender and recipient and a per-transaction anchor. Each receipt lands at a one-time address with no visible link to the recipient's published key. Same curve math as BIP-340/341/352.
• Confidential pool — a pool spend does not reveal which note it consumes, and amounts stay hidden on both chains. Only entry and exit are public.

The fixed-denomination Bitcoin mixer (T_DEPOSIT / T_WITHDRAW) is legacy; the confidential pool is the privacy surface for any amount.

What remains public:

• Asset id on Bitcoin transfers.
• Bitcoin addresses and the transaction graph, including the sender pubkey the recipient needs for ECDH recovery.
• The pool boundary — deposits into and withdrawals out of the confidential pool.
• AMM reserves and burn amounts. Trade sizes are hidden only in Bitcoin T_SWAP_BATCH and pool OP_SWAP_BLIND batches; live pool swaps settle as OP_SWAP_ROUTE, whose amounts show in the reserve change.
• The prover's witness. Whoever proves a pool batch sees its inputs. To keep them private, prove locally.

Recipient blinding: r_recip = HMAC-SHA256(SHA-256(ECDH_x), "tacit-blind-v1" ‖ anchor ‖ vout_LE) mod n, where anchor = first_asset_input_txid_BE ‖ first_asset_input_vout_LE. The per-transaction anchor gives every transfer between the same two parties fresh blindings, so commitments cannot be compared across transactions.

Sender's change blinding: r_change = HMAC-SHA256(sender_priv, "tacit-change-v1" ‖ anchor ‖ vout_LE), where vout_LE is the change output's index in the reveal tx. It is deterministic from the wallet key, so it is recoverable from the chain alone.

Etcher's supply blinding: r_supply = HMAC-SHA256(etcher_priv, "tacit-etch-v1" ‖ etch_anchor), where etch_anchor = first input outpoint of the commit tx. The anchor predates the envelope (a pre-existing UTXO), breaking the cycle that would otherwise arise from anchoring on the reveal txid. Scanners read it via reveal_tx.vin[0] → fetch commit tx → commit_tx.vin[0].

Each commitment also carries an encrypted amount (8 bytes, u64 LE XOR'd with an HMAC-keystream). For CXFER outputs, the keystream uses ECDH-derived keying for recipients (so recipient can decrypt with their priv + sender pub) and self-derived keying for change. For CETCH supply, the keystream is self-derived from etcher_priv + etch_anchor — only the etcher can decrypt; observers see opaque bytes. After decryption, the wallet verifies C == amount·H + r·G; tampering with the ciphertext makes verification fail.

For self-derived roles (CETCH supply, MINT amount, CXFER change), blinding and keystream are derived under distinct HMAC domain tags (tacit-etch-v1 vs tacit-etch-amount-v1; tacit-mint-blind-v1 vs tacit-mint-amount-v1) so the 8-byte keystream output cannot leak any structure of the 32-byte blinding scalar.

So share-links are optional notifications, not required for recovery. A fresh wallet with only its key finds its balance from the chain: incoming transfers via ECDH, and its own change, etches and mints via self-derived keys.

Every Bitcoin-side action is one of the operations below, carried inside an ordinary Bitcoin transaction.

The envelope version is 0x01, and every op is a commit/reveal pair carrying the envelope in tx.vin[0].witness[1] of the reveal. SPEC.md §3.9 is the canonical opcode map, with assigned, legacy and reserved bytes.

Core asset lifecycle

Marketplace (atomic offers + orderbook)

Legacy: mixer and claim pools

Native AMM (SPEC §3.5)

LP-staking farms (SPEC §3.5)

Legacy: wrapper attestations and cBTC.zk slots

Cross-chain and cBTC (SPEC §3.6–3.7)

Legacy: early tETH bridge

Wire-format examples below cover the core four (CETCH / CXFER / T_MINT / T_BURN). The other opcodes use the same envelope with their own payload layouts and rules — see SPEC.md §3.

Marketplace flows settle through T_AXFER and the preauth bids, with no separate opcodes: atomic intents (a seller publishes one signed offer and any taker settles it atomically on Bitcoin), preauth sales (the seller pre-signs, then goes offline), and batched takes (a buyer sweeps several preauths in one reveal tx, using position-independent SIGHASH_SINGLE|ANYONECANPAY). They share the kernel and range-proof checks of a plain CXFER; only the coordination differs.

Rangeproofs and aggregated payloads don't fit in 80-byte OP_RETURN, so payload moves into a Taproot script-path leaf. Each operation is 2 transactions: a commit tx that creates a P2TR output committed to the envelope's leaf hash (internal pubkey = BIP-341 NUMS, so script-path is the only spend), and a reveal tx that spends the P2TR via script-path, exposing the envelope script in the witness. Indexers scan tx.vin[0].witness[1] for envelopes.

Envelope leaf script

CETCH payload (opcode 0x21) — initial issuance

The wire format treats image_uri as opaque UTF-8 bytes. The decoder accepts any valid UTF-8 up to 256 bytes and does not enforce a URI scheme. Renderers MUST validate before display: tacit's UI accepts only ipfs://CID and bare CIDs (Qm…/bafy…), and rejects http:, https:, javascript:, data: and other schemes. Direct https:// images are rejected so viewing an asset never contacts an issuer-controlled host; IPFS images load through the gateways the CSP allows at img-src.

Asset_id = sha256(reveal_txid_BE ‖ 0_LE) (32 bytes). Supply commitment lives at vout 0 of the reveal tx. If mint_authority is all-zero, the asset is fixed-supply (BTC-style); otherwise the named pubkey can issue more via T_MINT.

CXFER payload (opcode 0x23) — confidential transfer

MINT payload (opcode 0x24) — issue more supply (mintable assets only)

commit_anchor = commit_tx.vin[0].txid_BE ‖ commit_tx.vin[0].vout_LE (the same anchor the issuer uses for the mint blinding/keystream). Binding it into mint_msg ties the issuer's signature to a specific commit/reveal pair so a witnessed mint envelope cannot be replayed into a different commit/reveal pair.

BURN payload (opcode 0x25) — destroy supply, public amount

This is how a wallet, or any independent indexer, works out what is valid and what each balance is. Anyone can re-run these steps and reach the same answer:

1. For each wallet UTXO, fetch parent tx; read vin[0].witness[1]; decode as tacit envelope.
2. Recursively validate the outpoint: walk the ancestry back to its CETCH root, validating each step. Each outpoint validates once and is memoized, so cost is O(N) over an ancestry of N steps. There is no depth cap.
3. Aggregated rangeproof verification. A single bulletproof per envelope covers all m commitments (m ∈ {1,2,4,8}). The walker can additionally batch proofs across the entire ancestry into one multi-scalar multiplication via bpRangeAggBatchVerify, with random per-proof scalars α_i, β_i ensuring soundness preservation.
4. For CETCH leaves (T_CETCH): only vout 0 is the supply commitment; no kernel; the rangeproof bounds the initial supply.
5. For MINT envelopes (T_MINT): vout 0 holds the new supply commitment. Validator confirms asset_id = sha256(etch_txid ‖ 0), recursively validates the CETCH ancestor, requires mint_authority ≠ 0, and verifies the issuer's BIP-340 sig under the authority's x-only pubkey. mint_msg binds commit_anchor (the commit-tx's first input outpoint), preventing replay of the envelope into a different commit/reveal pair.
6. For CXFER nodes (T_CXFER): every input outpoint must itself recursively validate; every input's parent (CETCH/MINT/CXFER/BURN) must declare the same asset_id; the aggregated rangeproof must verify; the kernel sig must verify under (ΣC_out − ΣC_in).xonly() over the kernel msg.
7. For BURN nodes (T_BURN): same as CXFER but the verifier reconstructs E' = ΣC_out + burned_amount·H − ΣC_in. N=0 is allowed (full burn, no change output, no rangeproof).
8. Any failure anywhere in the ancestry → the UTXO is flagged as inflation attempt and excluded from balance. markAll propagates the verdict to every sibling output of a failed envelope.
9. Resolve (amount, blinding) for the commitment: try local opening first, then trial-decrypt the on-chain amount_ct (ECDH against sender pubkey for incoming, self-derived for own change/etch/mint). Verify C == a·H + r·G. If known or recovered → balance += a; if neither path works → "ghost".

The confidential pool carries the note onto Ethereum and back, and lets it do more than move:

• One note, two chains. Wrap ETH or any token through the ConfidentialRouter, or bring value over from Bitcoin — both land as the same shielded note. From there it transfers, trades, or borrows, and can exit on either side.
• cUSD CDP. Borrow cUSD against cBTC. A position's collateral and debt are public so the CollateralEngine can price them, but the position cannot be linked to its owner. Minting needs 150% collateralization and liquidation is possible below 130%; a stability fee and savings rate are built in and dormant.
• cBTC. Mint cBTC 1:1 against an SP1-reflected Bitcoin lock; supply is bounded by reflected locks, not a price feed. tacBTC is its ERC-20 form. Each mint needs a wstETH escrow (1.5× the lock value today), slashable if the lock is spent without a redeem; it deters, it does not back the peg.
• LP farms. Bond LP shares to earn rewards. The FarmManager escrows the reward asset, so a farm never pays beyond what it holds.
• Reflection bridge. Bitcoin ⇄ Ethereum value moves by SP1 zero-knowledge reflection: a burn on one side is proven on the other and minted once, after Bitcoin blocks are 24 confirmations deep. No multisig or attestor set signs a bridge message.
• One unified address. Publish a single tacit1… address; senders don't need to know whether you're receiving on Bitcoin or in the confidential pool — it resolves to the right endpoint, and a send can wrap straight into a shielded note for the recipient.

Every one of these settles through the same conservation kernel as a plain transfer, so value-in equals value-out per asset, and any op can be relayed gaslessly with the fee bound inside the proof. See SPEC §6 for the cross-chain path.

See SPEC §2.8 for the canonical walkthrough.

On-chain commitments — Pedersen on secp256k1

Commitments: C = a·H + r·G, additively homomorphic. H is a NUMS generator (no known discrete log w.r.t. G) derived deterministically by hash-to-curve from the seed "tacit-generator-H-v1". The protocol carries C on chain; (a, r) stay private.

Rangeproofs — aggregated Bulletproofs + Bulletproofs+

Bünz et al. 2017, at n=64 bits — each committed value proven to lie in [0, 2⁶⁴). A single proof covers m ∈ {1, 2, 4, 8} commitments simultaneously via the inner-product argument, witness size O(log(n·m)). On secp256k1: 688 B at m=1, 754 B at m=2, 820 B at m=4, 886 B at m=8. The client batches the proofs along an ancestry into a single multi-scalar multiplication. A 64-bit range bounds one commitment to about 184 billion units at 8 decimals.

Bulletproofs+ (Chung et al. 2022) is the default for new transfers (T_CXFER_BPP) and every pool output: about 14% smaller at the same security level, with the same wire shape as the base opcode. Classic Bulletproofs stay valid, and the verifier picks the scheme by proof length.

Proof systems — SP1, range proofs, two small ceremonies

The confidential pool and reflection run on SP1 proofs, Bulletproofs+ range proofs and Schnorr kernels. None of these needs a Tacit ceremony (SP1 proofs are wrapped in Groth16 using SP1's own setup). Two Groth16 circuit sets over BN254, with Phase 1 from the Polygon Hermez ceremony, cover narrower jobs:

• Swap batch — the AMM circuits (amm_swap_batch 171K constraints at N≤16 traders, plus amm_lp_add and amm_lp_remove; pot18 Phase 1). BabyJubJub Pedersen openings, range checks and a uniform clearing price over hidden per-trader amounts. The amm_swap_batch key is compiled into the settle guest (OP_SWAP_BLIND) and the reflection guest (T_SWAP_BATCH). OP_SWAP_BLIND is enabled in the guest but not yet emitted by the relayer; its batcher sees the amounts, while the SP1 prover and the chain do not.
• Legacy mixer — withdraw.circom (Poseidon-Merkle leaf membership + nullifier reveal, pot14 Phase 1) for Bitcoin T_DEPOSIT / T_WITHDRAW only.

Chain commitments live on secp256k1; in-circuit work lives on BabyJubJub (the embedded curve over BN254 Fr). A 169-byte Camenisch–Stadler sigma proof binds the two, out-of-circuit, with no trusted setup, so no secp256k1 arithmetic runs inside the circuit.

Shielded-address primitive — blinded-pubkey commits

Opt-in: commit = recipient_pubkey + b·G, where b = HMAC(SHA-256(ECDH_x), domain ‖ network ‖ tx_anchor) mod n. The output pays to the commit, and the recipient spends it with sk + b mod n. Each receipt sits at a one-time address with no visible link to the recipient's published key. Same curve math as BIP-340 / BIP-341 / BIP-352; no ceremony. It composes with shielded amounts, and a plain pubkey recipient stays valid.

Negative amounts (mod N). A "−1000" is just N − 1000 as a scalar; bulletproofs reject any value outside [0, 2⁶⁴). The proof's inner-product argument cannot be satisfied for a value that doesn't fit in 64 bits, so the verifier rejects.

Unbalanced amounts (CXFER). Even with rangeproofs, a sender holding 100 USDV could try to construct outputs (30 to recipient, 200 to themselves) — both with valid rangeproofs — and mint 130 from nothing. Kernel signatures block this:

• Sender computes excess = Σr_out − Σr_in and signs kernel_msg with priv = excess (BIP-340 Schnorr).
• Verifier reconstructs E' = ΣC_out − ΣC_in from on-chain commitments. If amounts balance, E' = excess·G and the sig verifies under E'.xonly().
• If amounts don't balance, E' = δ·H + excess·G with δ ≠ 0. Producing a valid sig would require knowing the discrete log of H w.r.t. G, which is hard since H is NUMS.
• kernel_msg = sha256("tacit-kernel-v1" ‖ asset_id ‖ N_in ‖ inputs ‖ N_out ‖ outputs ‖ burned_amount_LE), binding the sig to all relevant fields and preventing replay across txs.

Unbalanced amounts (BURN). Same kernel construction with burned_amount made explicit: the verifier checks E' = ΣC_out + burned·H − ΣC_in = excess·G. The public burned_amount field is bound into kernel_msg so claiming a smaller burn than was actually destroyed shifts the message and breaks the sig.

Mint forgery. Only the holder of mint_authority's private key can issue valid T_MINT envelopes for an asset. The validator fetches the parent CETCH, confirms the asset is mintable (mint_authority ≠ zero), and verifies the issuer Schnorr sig under that x-only key. The signed message binds the commit_anchor (commit-tx's first input outpoint) so an observer cannot rewrap the on-chain envelope payload into their own commit/reveal pair. The mint itself is rangeproof-bounded to [0, 2⁶⁴) per envelope; the authority can mint any number of times.

Cross-asset confusion. A sender could declare a CXFER as USDV but spend GOLDC inputs. The indexer fetches each input's parent envelope, reads its declared asset_id (across all four opcodes — CETCH, MINT, CXFER, BURN — via a unified parent-resolver), and rejects the CXFER if any input's asset_id differs from the current claim.

Verifying a coin costs work proportional to its history: recursive validation is O(ancestry size) on a cold cache. Range proofs along the walk are batched into one multi-scalar multiplication, and memoization keeps later scans in the same session to O(new UTXOs). Deep ancestries are slow on a fresh device; a slow check affects speed only, never correctness.

Tacit's Groth16 circuits use two trusted-setup ceremonies, and every artifact is published on IPFS: the Powers-of-Tau lineage, each circuit's final zkey, the pinned verifying keys, and the Bitcoin-block beacon that seals each ceremony. Anyone can re-derive a pinned verifying key from its bundle. Soundness needs only one honest contributor; zero-knowledge never depends on the ceremony. CEREMONY.md lists every CID and hash.

Mixer ceremony — withdraw.circom

Phase 1 from the Polygon Hermez pot14 Powers of Tau; Phase 2 with 2,227 contributors, sealed by a beacon over Bitcoin block 948,824. Used by the legacy Bitcoin mixer, and available to any denominated anonymity pool built on Tacit.

Pinned VK

sha256 760829334a…ce933af

Ceremony bundle

ipfs://bafybeidq2…ltxy2u (ptau · zkey · vkey · transcript)

AMM ceremony — three circuits

Three independent Phase 2 chains under one shared pot18 Phase 1 (5,018 contributions for amm_swap_batch, 13,668 for amm_lp_add, 13,703 for amm_lp_remove), all sealed by a single beacon over Bitcoin block 951,267. Pool reserves are public; the circuits hide per-trader amounts. The production amm_swap_batch zkey is bafybeieb5haf…xefwqm.

Pinned VK bundle

ipfs://bafkreibjpe…iomp4

Ceremony bundle

ipfs://bafybeiheww…niuam (per-circuit zkeys · vkeys · transcripts)

The confidential pool, cBTC and the reflection bridge otherwise run on SP1 proofs, Bulletproofs+ and Schnorr kernels, which need no Tacit ceremony. The one exception is swap batches: the amm_swap_batch key above is compiled into both SP1 guests, for OP_SWAP_BLIND and T_SWAP_BATCH. See SPEC §2.8 for the full circuit walkthrough.

Full review history: AUDITS.md. The v1 release's agentic audits: Fable 5.1 lock checkpoint (the review that gated the deploy), an external automated review, and the Pashov solidity-auditor v4 round (24-agent, post-deploy, extended to the zkVM guest) — run after a week of live mainnet use.

What each surface relies on, beyond Bitcoin and Ethereum consensus and the soundness of SP1 and Groth16:

Confidential pool. The pool, router, asset factory and SP1 guests are immutable. The CollateralEngine and FarmManager are governed by a 2-of-4 ops multisig within fixed bounds, with a delay and notice before changes that work against borrowers or farmers. cUSD relies on the CollateralEngine's price feed. Ethereum → Bitcoin reflection relies on the sp1-helios sync committee. Relayers, the hosted API and IPFS gateways cannot change validity; anyone can prove locally and call settle.

Issuer at CETCH. The initial supply commitment is hidden, so no kernel-sig constraint applies — the issuer chooses any value in [0, 2⁶⁴). The dApp publishes the (supply, blinding) opening by default in the asset's IPFS metadata, so anyone can check C == supply·H + r·G against the on-chain commitment. An issuer can opt out to keep the total confidential.

Mint authority for mintable assets. If mint_authority ≠ 0 in the CETCH envelope, that x-only pubkey can issue additional supply via T_MINT envelopes — bounded only by 2⁶⁴ per envelope, unlimited in count. Holders trust whoever holds that key. The dApp attests every mint by default so supply stays auditable. Fixed-supply CETCHes (mint_authority all-zero), such as TAC, can never be expanded.

T_PETCH (permissionless mints). No issuer trust at all. The deploy declares cap_amount, mint_limit, and an optional height window; deployer receives zero tokens. Each T_PMINT reveals (amount, blinding) on chain, so cumulative supply against the cap is auditable from chain alone — no attestation channel needed.

Ceremony circuits. Soundness of the legacy mixer circuit and the three AMM circuits rests on at least one honest contributor per Phase 2 chain; zero-knowledge does not depend on the ceremony. The amm_swap_batch key is the only ceremony key the confidential pool uses, for OP_SWAP_BLIND. On Bitcoin, AMM reserves are public numbers the indexer tracks and no UTXO holds pool funds; Groth16 binds hidden per-trader amounts in T_SWAP_BATCH to public batch deltas.

cBTC / tacBTC. Minted from SP1-reflected Bitcoin locks plus a CollateralEngine wstETH escrow (1.5× the lock today). Total cBTC cannot exceed reflected locked sats; the price feed only sizes the escrow. Custody is economic: the locker holds the key, and the escrow makes spending the lock unprofitable.

After issuance. No participant can inflate (kernel sig blocks unbalanced CXFER / T_AXFER / T_BURN; T_PMINT caps are chain-auditable; AMM circuits bind hidden amounts to public deltas), burn covertly (BURN's burned_amount is public and bound into the kernel msg), or substitute assets (asset_id consistency checked across every input's parent envelope). Recursive client-side validation guarantees this independent of any indexer's honesty.
